RJ-901C/RJ-900C Maintenance Manual 10 Appendix
10-7
10.4 Jigs and Tools
This section provides lists of jigs and tools required for service operations.
10.4.1 Required Tools
(1) Tools for Part Replacement
(2) Tools for Adjustment
Table 10-2 Tools for Part Replacement
No. Name Part number Remarks
1 Phillips driver No.2 Generic product More than 250mm shaft length is
recommended
2 Phillips driver No.2 Generic product Less than 50mm shaft length is
recommended
3 Phillips driver No.1 Generic product
4 Flat-head driver Generic product
5 Longnose plier Generic product
6 Tweezers Generic product
7 Hex wrench (opposite side:
6mm)
Optional stand
accessory (Generic
product)
Required only when disassembling legs
8 Head washer jig assembly JD-30410 - Including optional rubber bush, mini
fitting
- Required four sets per product
9 Rubber bush JD-42052 Consumable (To be replaced every 20
times)
10 Mini-fitting JD-42053/Generic
product
Manufacturer: Iuchi Seieidou
11 Shipping liquid S46 (C) JD-42263 Volume: 18 liters
Table 10-3 Tools for Adjustment
No. Name Part number Remarks
1 Personal computer Generic product
2 Tension gauge Generic product Max. 10,000gf (100N) for measurement
3 Tension gauge Generic product Max. 4,000gf (40N) for measurement
4 A4 matte film "Dia mat super A4"
manufactured by
Kimoto Co.,Ltd
Used for media sensor adjustment
(P_REAR sensor and P_EDGE sensor)
5 Coated paper Exclusive use media For plot quality adjustment
6 Straight scale (1000mm) Generic product
