4 Parts Replacement RJ-901C/RJ-900C Maintenance Manual
4-44
NOTE
When installing the cutter solenoid, note the following.
• Joint the cutter cap and the CR lock kicker, push down the cutter cap and the CR lock kicker
together to install them onto the cutter holder.
• Make sure to join the cutter cap and the CR lock kicker.Otherwise, when turning the power ON,
the carriage cannot move from the origin point to the left.
No. Part name
1 CR lock kicker
2
Cutter cap
To Next Page
