MUTOH Ultima 850 - Speed Selection; Offset Selection

Mutoh Ultima Multi-Purpose Cutting Plotter - Operation Instructions
28
AP-75125, Rev 1.3 ; 20/10/04
Step 6 : Press the [ENTER] key to confirm the FORCE selection.
Notes :
To cancel the changes of the parameter, press the [CANCEL] key. The display will
show the previous value for the parameter.
When you press the [EXIT] key the changed value will be ignored and you go back to
the previous menu.
3.2.2. Speed selection
To change / control the speed, please perform the instructions mentioned bow.
Step 1 : Press the [SPEED] key.
Step 2 : The actual SPEED setting for the selected tool will now be shown on the display. Viewing of the
value can be performed in PAUZE as well as in READY mode.
Speed
Actual : 10
New : 10
In cm/s
Notes :
Changing/viewing of the value can be performed in BUSY mode. Please note that the
effect can only be seen after a few seconds.
Step 3 : Press the [UP] or [DOWN] key to change the force setting.
Step 4 : Press the [ENTER] key to confirm the SPEED selection.
Notes :
To cancel the changes of the parameter, press the [CANCEL] key. The display will
show the previous value for the parameter.
When you press the [EXIT] key the changed value will be ignored and you go back to
the previous menu.
3.2.3. Offset selection
One of the most important factors to obtain good quality, but unfortunately also one of the factors that is
easily forgotten, is the offset.
For more information about the offset, please refer to the chapter ‘Finetuning your cutter to obtain Mutoh
quality’.
