Mutoh Ultima Multi-Purpose Cutting Plotter - Operation Instructions
34
AP-75125, Rev 1.3 ; 20/10/04
3.3. CONTOUR CUTTING
Notes :
In case the software is not supporting the Ultima contour cutting function, you can use
the [CONTOUR CUTTING] key to perform contour cutting.
To perform an alignment, please follow the instructions mentioned below.
Step 1 : Load the printed media into the cutting plotter.
Step 2 : Install a knife.
Step 3 : Power ON the cutting plotter. The cutting plotter will perform a shuffle sequence.
Step 4 : Press the [CONTOUR CUTTING] key.
Contourcutting :
Methods :
→ Automatic
Start alignment
Step 5 : By using the [UP] and [DOWN] key you select ‘manual’, ‘automatic’ or ‘bar code’.
Notes :
Before performing an alignment, ‘X Length’, ‘Y Width’ and ‘Roll Direction’ must be
inserted. With these values the Ultima cutting plotter will calculate the E-pos correction.
Step 6 : Press the [CONTOUR CUTTING] key. On the display following message will appear.
Contourcutting :
X Length (mm) :
→ 500
Start alignment
Step 7 : By using the [UP] and [DOWN] key you select an appropriate value for the X Length.
Notes :
Please make sure that the value of the X Length is smaller than the length of the loaded
media. Otherwise, the Ultima cutting plotter cannot complete the alignment.
