MUTOH Ultima 850 - Page 35

Mutoh Ultima Multi-Purpose Cutting Plotter - Operation Instructions
35
AP-75125, Rev 1.3 ; 20/10/04
Step 8 : Press the [CONTOUR CUTTING] key to confirm. On the display following message will appear.
Contourcutting :
Y Width (mm) :
→ 500
Start alignment
Step 9 : By using the [UP] and [DOWN] key you select an appropriate value for the Y Width.
Step 10 : Press the [CONTOUR CUTTING] key to confirm. On the display following message will appear.
Contourcutting :
Roll direction
→ Non-reverse
Start alignment
Step 11 : Select the appropriate ‘roll direction’ (non-reverse or reverse) by using the [UP] and [DOWN] key.
Step 12 : Press the [CONTOUR CUTTING] key to check the entered values of the ‘X length’, ‘Y width’ and
‘roll direction’.
Step 13 : To confirm your settings press the [ENTER] key.
Step 14 : The Ultima cutting plotter will start the frame detection. (‘manual’ or ‘automatic’ as selected in
step 5).
In case you selected ‘Automatic’.
Step 15 : The Ultima cutting plotter will automatically measure the four alignments points.
In case you selected ‘Manual’.
Step 15 : After pressing the [ENTER] key following message will appear on the display.
Manual alignment
method
please select
the point
Step 16 : Use the [JOGG] keys to select the first alignment point (P1). Press the [ENTER] key to perform.
Step 17 : The Ultima cutting plotter will move the head toward the second alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 18 : Use the [JOGG] keys to select the second alignment point (P2). Press the [ENTER] key to
perform.
