Mutoh Ultima Multi-Purpose Cutting Plotter - Operation Instructions
36
AP-75125, Rev 1.3 ; 20/10/04
Step 19 : The Ultima cutting plotter will move the head toward the third alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 20 : Use the [JOGG] keys to select the third alignment point (P3). Press the [ENTER] key to perform.
Step 21 : The Ultima cutting plotter will move the head toward the last alignment point. On the display
following message will appear.
Manual alignment
method
please select
the point
Step 22 : Use the [JOGG] keys to select the fourth alignment point (P4). Press the [ENTER] key to
perform
Step 23 : Manual alignment is completed.
Notes :
Make sure to keep the order of the alignment points. P1, P2, P4 and then P 3
In case you selected ‘Auto Barcode’.
Step 1: After pressing the [CONTOUR CUTTING] key following message will appear on the display.
Contourcutting:
→ Repeat Mode
Start aligning
Step 2: Select the appropriate ‘mode’ (repeat mode, single scan) by using the [UP] and [DOWN] key
Step 3: Press the [ENTER] key.
