AP-76942_Rev 1.0 Page 5/19
2 Cleaning around the print head
(1) Cleaning frequency
On a weekly basis, check if foreign substances (ink clots that can cause missing dots or ink
leakage) are attached around the print head. If it is the case, remove them as described.
(2) Cleaning procedures
Step 1: If the printer is powered ON, make sure that printing or other operations are not in
progress.
Step 2: Display the CR Maintenance menu
Press the [Menu] key
“Menu1: Setup>” is displayed.
The operation panel shifts to the Setup menu display.
Press [>].
“Set1: UserType” is displayed
Press [+] or [–] to select “Set20: CR Maintenance”.
Press [Enter].
“CR Mainte.: Start” is displayed.
The display enters the CR Maintenance menu.
Step 3: Press the [Enter] key
Maintenance starts.
The print head moves to the left.
“CR Maintenance: End” is displayed
Step 4: Open the left maintenance cover.
Note
Before cleaning around the print head, read this procedure thoroughly to fully
understand it, and clean promptly and correctly.
While cleaning around the print head, the print head cap is removed, therefore
cleaning must be done before the print head dries.
Leaving the print head at the replacement position for a long time, may result in
clogging of the print head. Please limit to 15 minutes
Use the cleaning stick to clean around the print head.
To Next Page
