5.1.27 Single Head menu
You can set whether or not to perform printing using only one Print head.
NOTE
NOTE
 This printer has 2 Print heads inside Print head unit.Data Header
 Even if "Head 1" or "Head 2" is set, when performing the Test print menu, the both Print heads are used
for printing.
 When "Head 1" or "Head 2" is set, if "A-S. Fine&Wave" or "B-S.Fine&Wave" is selected, the selected Print
head is further divided for printing.
Setup Item Set Value Description
<Off> Both Print heads are used for printing.
Head1 Only left Print head is used for printing
Head2 Only right Print head is used for
printing.
Single head
− [Cancel] Key: Save the set value, and
return to the previous menu.
