VJ-2638/1638X/1938WX/1638WX OPERATION MANUAL Before using
3.6 Print quality adjustment 143
• The confirmation pattern will be printed.
• After the confirmation pattern is printed, Operation panel returns to "Adj. 1: Confirm Ptn.".
• Because this printer has 2 Print heads, 2 rows of confirmation pattern will be printed.
4. Confirm that the confirmation pattern printing result is as follows.
a. When the printing result is Good;
You do not need perform print quality adjustment.
The procedure for print quality adjustment is complete.
b. When the printing result is Not good;
You need to perform print quality adjustment.
• Perform rough adjustment when the degree of misalignment is big.
3.6.1.2 Standard rough adjustment pattern
• Perform micro adjustment when the degree of misalignment is small.
3.6.1.3 Standard micro adjustment pattern
To Next Page
