Chapter 7 Related Documents
Compound 2-stage Screw Compressor 2016**C 7.2 Development Views, Assembly Sectional Views, and Parts Configuration Tables
7-15
No. Part name Code No. Remarks
Q’ty.
LLC LMC LSC MSC SSC
43-1
Thrust Bearing Gland
(1)
CS04300-200S 200*** 2 2 2 2 2
43-2
Thrust Bearing Gland
(2)
CS043002016C2B 2016**C 2 2 2 2 2
45-1 Hexagon Head Bolt NB111012-035 M12×35 8 8 8 8 8
45-2 Hexagon Head Bolt NB111010-030 M10×30 8 8 8 8 8
46-1 Lock Washer (1) ND150-012 200*** 8 8 8 8 8
46-2 Lock Washer (2) ND150-010 160*** 8 8 8 8 8
48 Retainer, Oil Seal CS04800-200VDS 200*** 1 1 1 1 1
49 O-ring PA12-115 JISB24011AG115 1 1 1 1 1
50 Oil Seal CS05010-200VD SA1J 65×85×12 1 1 1 1 1
51 Seal Cover CS05100-200 200*** 1 1 1 1 1
51 Seal Cover CS05100-200HE 200*** (for HE) 1 1 1 1 1
52 Gasket, Seal Cover CS05200-200N 200*** 1 1 1 1 1
53
Hexagon Socket Head
Cap Screw
NB35410-025 M10×25 8 8 8 8 8
54-1
Unloader Slide Valve
(1-1) (L port)
CS05400-2016**** 2016LSC 1 1 1 - -
54-1
Unloader Slide Valve
(1-1) (M port)
2016LSC 1 1 1 - -
54-1
Unloader Slide Valve
(1-1) (L port)
2016MSC - - - 1 -
54-1
Unloader Slide Valve
(1-1) (M port)
2016MSC - - - 1 -
54-1
Unloader Slide Valve
(1-1) (L port)
2016SSC - - - - 1
54-1
Unloader Slide Valve
(1-1) (M port)
2016SSC - - - - 1
54-2
Unloader Slide Valve
(1-2) (L port)
2016*SC - - 1 1 1
54-2
Unloader Slide Valve
(1-2) (M port)
2016*SC - - 1 1 1
54-2
Unloader Slide Valve
(1-2) (H port)
2016MSC - - - 1 -
54-2
Unloader Slide Valve
(1-2) (L port)
2016LLC 1 - - - -
54-2
Unloader Slide Valve
(1-2) (M port)
2016*LC 1 - - - -
54-2
Unloader Slide Valve
(1-2) (L port)
2016LMC - 1 - - -
54-2
Unloader Slide Valve
(1-2) (M port)
2016*MC - 1 - - -
55-1
Unloader Slide Valve
(2-1)
200L** 1 1 1 - -
55-1
Unloader Slide Valve
(2-1)
200M** - - - 1 -
55-1
Unloader Slide Valve
(2-1)
200S** - - - - 1
55-2
Unloader Slide Valve
(2-2)
160L** 1 - - - -
55-2
Unloader Slide Valve
(2-2)
160M** - 1 - - -
55-2
Unloader Slide Valve
(2-2)
160S** - - 1 1 1
58-1
Hexagon Socket Head
Cap Screw
NB35410-030 M10×30 4 4 4 4 4
58-2
Hexagon Socket Head
Cap Screw
NB35408-025 M8×25 4 4 4 4 4
59 O-ring PA11-020 JISB2401 1A P20 1 1 1 1 1
