Chapter 7 Related Documents
Compound 2-stage Screw Compressor 2016**C 7.2 Development Views, Assembly Sectional Views, and Parts Configuration Tables
7-16
No. Part name Code No. Remarks
Q’ty.
LLC LMC LSC MSC SSC
60-1 Unloader Cylinder CS06000-2016C 2016LSC 1 1 1 1 1
60-2 Unloader Cylinder CS06000-160L 160L** 1 - - - -
60-2 Unloader Cylinder CS06000-160M 160M** - 1 - - -
60-2 Unloader Cylinder CS06000-160S 160S** - - 1 1 1
61
Hexagon Socket Head
Cap Screw
NB35410-025 M10×25 2 2 2 2 2
62-1
Hexagon Socket Head
Cap Screw
NB35410-110 M10×110 8 8 8 8 8
62-2
Hexagon Socket Head
Cap Screw
NB35410-065 M10×65 6 6 6 6 6
63 O-ring PA12-125 JISB2401 1A G125 2 2 2 2 2
64-1 Unloader Piston (1) CS06400-2016T 2016LSC 1 1 1 1 1
64-2 Unloader Piston (2) CS06400-160T 160*** 1 1 1 1 1
65 O-ring PA11-100 JISB2401 1A P100 2 2 2 2 2
66 Cap Seal CS06600-160 CAP-1BE100 2 2 2 2 2
67-1
Push Rod, Unloader
Slide Valve (1)
CS06700-2016C1 2016LSC 1 1 1 1 -
67-1
Push Rod, Unloader
Slide Valve (1)
CS06700-2016SSC 2016SSC - - - - 1
67-2
Push Rod, Unloader
Slide Valve (2)
CS06700-2016C2 2016LSC - - 1 1 1
67-2
Push Rod, Unloader
Slide Valve (2)
CS06700-2016LLC 2016LLC 1 - - - -
67-2
Push Rod, Unloader
Slide Valve (2)
CS06700-2016LMC 2016LMC - 1 - - -
68-1 Guide Pin NE2505-012 Φ5×12 1 1 1 1 1
68-2 Guide Pin NE2503-008 Φ3×8 1 1 1 1 1
69-1 Lock Nut (1) NG31-007 AN07 1 1 1 1 1
69-2 Lock Nut (2) NG31-005 AN05 1 1 1 1 1
70-1 Lock Washer (1) NG32-007 AW07 1 1 1 1 1
70-2 Lock Washer (2) NG32-005 AW05 1 1 1 1 1
71-1 Lock Nut (1) NG31-007 AN07 1 1 1 1 1
71-2 Lock Nut (2) NG31-005 AN05 1 1 1 1 1
72-1 Lock Washer (1) NG32-007 AW07 1 1 1 1 1
72-2 Lock Washer (2) NG32-005 AW05 1 1 1 1 1
73-1 O-ring PA12-030 JISB2401 1A G30 1 1 1 1 1
73-2 O-ring PA11-021 JISB2401 1A P21 1 1 1 1 1
74-1
Unloader Cylinder
Cover (1)
CS07400-2016S 2016LSC 1 1 1 - 1
74-1
Unloader Cylinder
Cover (1)
CS07400-2016MSC 2016MSC - - - 1 -
74-2
Unloader Cylinder
Cover (2)
CS07400-160S 160*** 1 1 1 1 1
74-2
Unloader Cylinder
Cover (2)
(Explosion-Proof
Type)
CS07460-160 160*** 1 1 1 1 1
75 O-ring PA12-110 JISB2401 1A G110 2 2 2 2 2
76-1
Hexagon Socket Head
Cap Screw
NB35408-030 M8×30 8 8 8 8 8
76-2
Hexagon Socket Head
Cap Screw
NB35408-025 M8×25 8 8 8 8 8
77-1 Indicator CAM (1) CS07700-2016C 2016LSC 1 1 1 - -
77-1 Indicator CAM (1) CS07700-2016MSC 2016MSC - - - 1 -
