2200LZJE-HO-C6-N_2013.12.
Chapter 7 Related Documents
Compound 2-stage Screw Compressor 2016**C 7.2 Development Views, Assembly Sectional Views, and Parts Configuration Tables
7-17
No. Part name Code No. Remarks
Q’ty.
LLC LMC LSC MSC SSC
77-1 Indicator CAM (1) CS07700-2016SSC 2016SSC - - - - 1
77-2 Indicator CAM (2) CS07700-160L 160L** 1 - - - -
77-2 Indicator CAM (2) CS07700-160M 160M** - 1 - - -
77-2 Indicator CAM (2) CS07700-160S 160S** - - 1 1 1
78 Ball Bearing CS07800-200 #6000 2 2 2 2 2
79 Stop Ring NG12-010 S10 2 2 2 2 2
80 Bearing Gland CS08000-200 200*** 2 2 2 2 2
81
Hexagon Socket Head
Cap Screw
NB35406-015 M6×15 6 6 6 6 6
82 V-ring CS08200-200B 20×10×12 2 2 2 2 2
83 Spring CS08300-200 200*** 2 2 2 2 2
84
Retainer, Indicator
Cam Spring
CS08400-200 200*** 2 2 2 2 2
85 Oil Injection Pipe CS08500-200LUK 200LU* 1 1 1 - -
85 Oil Injection Pipe CS08500-2016MSC 2016MSC - - - 1 -
85 Oil Injection Pipe CS08500-2016SSK 2016SSC - - - - 1
86 O-ring PA11-021 JISB2401 1A P21 1 1 1 1 1
87-1 Guide Block (1) CS08700-200 200*** 1 1 1 1 1
87-2 Guide Block (2) CS08700-160 160*** 1 1 1 1 1
88-1 Stem, Guide Block (1) 200&250*** 1 1 1 1 1
88-2 Stem, Guide Block (2) 160*** 1 1 1 1 1
89-1 O-ring PA11-020 JISB2401 1A P20 2 2 2 2 2
89-2 O-ring PA11-016 JISB2401 1A P16 2 2 2 2 2
91 Shaft key (1) CS09100-200 200*** 1 1 1 1 1
92-1 Suction Flange (1) CS71300-150 JIS20K 150A(6") 1 1 1 1 1
92-2 Suction Flange (2) CS71300-100 JIS20K 100A(4") 1 1 1 1 1
93-1
Gasket, Suction
Flange (1)
CS71200-150N JIS20K 150A(6") 1 1 1 1 1
93-2
Gasket, Suction
Flange (2)
CS71200-100N JIS20K 100A(4") 1 1 1 1 1
94-1 Hexagon Head Bolt NB12022-055 M22×55 12 12 12 12 12
94-2 Hexagon Head Bolt NB12020-055 M20×55 8 8 8 8 8
95-1 Discharge Flange (1) CS71300-100 JIS20K 100A(4") 1 1 1 1 1
95-2 Discharge Flange (2) CS71300-080 JIS20K 80A(3") 1 1 1 1 1
96-1
Gasket, Discharge
Flange (1)
CS71200-100N JIS20K 100A(4") 1 1 1 1 1
96-2
Gasket, Discharge
Flange (2)
CS71200-080N JIS20K 80A(3") 1 1 1 1 1
97-1 Hexagon Head Bolt NB12020-055 M20×55 8 8 8 8 8
97-2 Hexagon Head Bolt NB12020-055 M20×55 8 8 8 8 8
100
Mechanical Seal
Assembly (BBSE)
CS10002-200EBS BBS-E 1 1 1 1 1
120-1
Unloader Indicator
Assembly (1)
CS12000-1612F 1612LSC 1 1 1 1 1
120-2
Unloader Indicator
Assembly (2)
CS12000-200F 200*** 20-100% 1 1 1 1 1
151 Driven Sleeve CS15100-2016 1 1 1 1 1
152 Drive Hub 1 1 1 1 1
153 Driven Hub 1 1 1 1 1
154
Stopper, Driven
Sleeve
CS15400-2016C 2 2 2 2 2
155 Stop Ring FRS-90 4 4 4 4 4
To Next Page
