Standard and X.. Project series
sensor menu
(magnet and sensor placed
on barbotin)
Sensor Calibrat
Barb. Circ. 3 3 . 0
D i v i s o r f a c t . 1
E x i t
1000 – 1500 –2000 W Project series
sensor menu
(magnet and sensor placed
on motor)
Sensor Calibrat
Red. Factor 5 7 . 0
E x i t
Barbotin Circumference
In this row the user must enter the
circumference of the gipsy (in centimetres or
inches). Use the Table 1 provided to
calculate the circumference.
Settable values: centimetres or inches.
Default value, 33 cm.
Division Factor
If you use the 3-wire inductive sensor set
here the number of signatures of the gypsy
obtained from Table 1.
If you use the 2-wire magnetic sensor leave
the value set to 1.
Reduction Factor
In this row the user must enter the reduction
factor. See next Table 2 for the correct value
to be entered
Default value, 57.
Select with Select value with Confirm with
Exit
To return to the settings menu.
Confirm with
Table 1 - Standard and Project X.. series sensor
(magnet and sensor placed on barbotin)
Chain Type Number of recesses
Gipsy Circumference
(cm)
Gipsy Circumference
(inches)
6 22 9
6 mm
9 34 13
7 mm 6 25 10
5 24 9
6 28 11
7 33* 13
8 mm
8 38 15
5 31 12
10 mm
6 36 14
5 36 14
12 mm
6 43 17
13 mm 6 46 18
14 mm 5 42 16
* factory settings of instrument
