MZ electronic EV-040 - Page 2

Part. C
Part. A
magnetic sensor
sensore magnetico
Fig. 2A Fig. 2B
Fig. 2C
sensor cable
cavo sensore
Fig. 1A
magnetic sensor
sensore magnetico
G2
G1
Part. B
Part. A
sensor cable
cavo sensore
magnet
Fig. 1B
magnete
min.44 mm(1”3/4)
