N4L PPA55 Series User Manual

PPA55xx Quick User Guide
Page 17
RANGE
Input channel options
Voltage Input
Internal
The internal voltage attenuator selects the 4mm
connections on the rear of the instrument and has a
max input of 3000Vpk
External Attenuator
(for connection to a HF
shunt).....etc
An External Sensor / Shunt can be connected to the
instrument which will give the operator more
versatility in selecting the Input range required. Note:
if this option is selected then the resulting data is
scaled by the appropriate value within the attenuator
and scale factor sub section. Max input of 3Vpk
Autoranging
Full Autorange
Default setting. Full autoranging will be selected and
implemented within the instrument
Range up only
Selecting this option will allow the test being carried
out to find the highest range via peak detection and
hold on this range. Once this value has been found
another test can be carried out by pressing the
"Trigger" button which will restart from the minimum
value set parameter use for "Low” Frequency
measurements
Manual
Selecting this option will allow the user to set up the
range from the configured measurements available,
this is useful for inrush testing when a mid-analysis
range change is not desirable
Minimum Range
Pre set Input Voltage minimum range
300mV
Minimum Input Voltage range will not be below
300mv
1V
Minimum Input Voltage range will not be below 1v
3V
Minimum Input Voltage range will not be below 3v
10V
Minimum Input Voltage range will not be below 10v
30V
Minimum Input Voltage range will not be below 30v
100V
Minimum Input Voltage range will not be below 100v
300V
Minimum Input Voltage range will not be below 300v
1Kv
Minimum Input Voltage range will not be below 1Kv
3Kv
Minimum Input Voltage range will not be below 3Kv
Scale Factor
Manually set the scale factor required, normally used
in conjunction with current transformers
