N4L PPA55 Series - Rear Panel Layout Diagram

PPA55xx Quick User Guide
Page 30
4 Rear Panel Layout
1. Voltage & Current External Analogue Inputs
2. Voltage & Current Internal Inputs
3. Mains Supply Inlet
4. Communication Ports
5. Auxiliary Ports
6. Master / Slave Connection Port
1 2
6 5 4 3
