N4L PPA55 Series User Manual

PPA55xx Quick User Guide
Page 24
Screen Print
Disabled
No Screen print option selected
RS232
Print screen via RS232 Cable i.e. to printer
USB Memory Stick
Print screen directly onto USB memory stick
AUX
Master / Slave
Select if 2 x PPA55xx units are to be used as a
PPA5540/50/60
Disabled
Master / Slave configuration disabled
Master
Select to set PPA55xx as master unit within
4 -6 phase configuration
Slave
Select to set PPA55xx as slave unit within
4 - 6 phase configuration
Simple Slave
In simple slave mode the results window is not
synchronised between the 2 units, the master unit will
only ask the slave unit for the results from the Watts
measurement
Auxiliary Device
None
No Auxiliary device connected
PCIS Inrush Switch
Phase Controlled Inrush Switch – is an active device
which is controlled over the extension port within the
instrument. It accurately synchronises to the line
input, measures the frequency and switches on the
output at a precise phase angle selected from the
instruments front panel. Useful for testing inrush
current of ballasts
SYS
Set Clock
Manual Setting Required. Use Numerical Keys
Set Date
Manual Setting of Date and Year, Month settings are
preset
Display
Colour
Display data will be in colour
White on Black
Display data will be displayed as white font on black
background
Black on White
Display data will be displayed as black font on white
background
Brightness
Low
Screen brightness set to Low
High
Screen brightness set to High
