PPA55xx Quick User Guide
Page 23
Alarm 2 Data
Alarm on selected parameter and thresholds
Zoom 1
Zoom 1 parameter selected for alarm threshold
Zoom 2
Zoom 2 parameter selected for alarm threshold
Zoom 3
Zoom 3 parameter selected for alarm threshold
Zoom 4
Zoom 4 parameter selected for alarm threshold
Alarm Type (Alarm 2)
Disabled
No alarm
Alarm if high
Alarm will sound if values exceed a threshold
Alarm if low
Alarm will sound if values fall below a threshold
Outside window
Alarm will sound if values are outside a permitted
window setting
Inside window
Alarm will sound if values are within a permitted
window setting
Analogue Output
Disabled
No analogue output
Zoom 1
Set an analogue output voltage representative of
zoom 1
Zoom 2
Set an analogue output voltage representative of
zoom 2
Zoom 3
Set an analogue output voltage representative of
zoom 3
Zoom 4
Set an analogue output voltage representative of
zoom 4
Manual
Set a constant analogue output voltage
REMOTE
Resolution
Press to set the data resolution and change the
format to which the instrument responds to future
commands, via Comms interface
Normal
Data Resolution set to 5 decimal points
High
Data Resolution set to 6 decimal points
Binary
Data transmitted in Binary Format
Interface
Communications type between instrument and pc
RS232
RS232 Comms interface
USB
USB Comms interface
LAN
LAN Comms interface
GPIB
GPIB Comms interface
Recall with Program
When enabled recalls communication port settings
from any stored memory location
Off
Turn OFF this option
On
Turn ON this option
