PPA55xx Quick User Guide
Page 28
Increase font size on selected parameters on display
screen
Decrease font size on selected parameters on display
screen
Press Real Time to return to the display screen and
see all data in real time. Pressing the real time button
will also put the display screen into hold mode
Press Table to view results either during or at the
completion of a Datalog in tabular format, this is also
the default screen whilst Datalog is running
Press Graph during Datalog to view plotted data
points whilst log is in process, or view graph plots
once Datalog is complete. Press “GRAPH” to move
through screen display options
Direct button to Power Analyzer mode functions
Direct button to Power Integrator mode functions
Direct button to Harmonic Analyzer mode functions
Direct button to True RMS Voltmeter mode functions
Direct button to Impedance Analyzer mode functions
Direct button to Scope mode where waveforms can be
viewed from measurements being taken. The left and
right directional arrows will allow the time base to be
changed and the up and down arrows will allow the
trigger level to be set
Start button will start any Datalog. Is also the button
used to initialise a screen dump of any data displayed
onto a USB memory stick
