Wiring Diagrams (General) 7-25
Rev. 9-09-16 Part #C-00084
www.NabcoEntrances.com Magnum 4A Control Wiring and Adjustment Manual
P/N 14-2101
ROCKER SWITCH
RED
WHITE
BLACK
PART # 21-9934
300/400/500 HARNESS
FOR MAGNUM BOARD
ORANGE
VIOLET
WHITE
RED
BLACK
BROWN
EXIT
AUTO
ACUSENSOR
ACUVISION
6
5
4
3
2
1
ACUSENSOR
FOLD SIDE
APROACH SIDE
FOLD SIDE
ON
OFF
HOLD OPEN
RED
WHITE
BLACK
GREENGREEN
RED
WHITE
BLACK
GREEN
RED
BLUE
BROWN
WHITE
14-8902
14-8902
14-10823-01
ACUSENSOR HARNESS
22-9184
ACUSENSOR HARNESS
22-9184
ACUVISION HARNESS
22-11023
MAGNUM CONTROL BOARD
120 VAC
TRANSFORMER
BLACK
RED
PART # 22-10065
MAIN HARNESS
14-14362
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
WHITE
GREEN
GREEN
WHITE
WHITE
120 VAC "HOT"
120 VAC "NEUTRAL"
SERVICE GROUND
MINIMUM 5 AMPERE SERVICE
PER OPERATOR
NOTES:
1. WIRES AT SENSOR CONNECTORS AND SWITCH CONNECTORS
IN THIS DRAWING DO NOT REPRESENT THE ORDER OF THE
WIRES AT THAT CONNECTOR.
2. SENSORS OR OTHER ACTIVATION DEVICES MUST USE
NORMALLY OPEN DRY CONTACTS FOR TRIGGERING
FOR RIGHT HAND OPERATORS,
MATCH MOTOR WIRES,
RED TO RED, BLACK TO BLACK.
FOR LEFT HAND OPERATORS,
MIS-MATCH THE MOTOR WIRES,
RED TO BLACK, BLACK TO RED.
MAGNUM CONTROL
MOUNTING BRACKET
FOR FOLDING DOORS
N.C. BREAK-OUT SWITCHES
POWER
SWITCH
O
F
F
12 43
AUX
PWR
J2
J5
AC IN
F2
SW2
SW1
F1
R2
R3
R4
R5 R6
R7
R8
TDAS TDPG LCHK CLOSESTOP OPEN BCHK
CURRENT
LIMIT
MOTOR
J1
R28
MAGNUM 4A
LED
TRANSFORMER
RELAY
RELAY
J4
SIGNAL
INPUT
CAPACITOR
C26
D10
MOV3
DN 0691
