uPC1237HA
MAIN BOARD: IC44
Overload Detector
Output Offset Detector
Switch for latch/automatic --reset
Flip--Flop
VCC ON
MUTE
AC---OFF detector
Relay driver
1
2
43
5
78
6
GND
VCC
ICS BLOCK DIAGRAM
1
8
8PIN PLASTIC SLIM SIP
