NAD C 325BEE - Exploded View Parts List

REF.NO PART NO. DESCRIPTION Qty. REF.NO PART NO. DESCRIPTION Qty.
C001
66-065001-0
Chassis 1 F016 01-32503-00 KEYBOARD ASSEMBLY 1
C002
66-001004-1 Base Cover
1 F017
74-065001-0 Power Button
1
C003
75-010004-0 Foot
4 F018
92-048001-0 Spring For Button
1
C004
78-001002-0 Foot Pad
4 F019
01-32508-00 Standby Board Assy
1
C005
01-32501-10 Main Board Assy(AH)
1 F020
01-32504-00 Phone Board Assy
1
01-32501-20 Main Board Assy(C)
1
C006
01-32505-10 Power PCB (AH)
1
01-32505-20 Power PCB (C)
1
C007
70-065003-0 Heatsink
1 R001
67-065001-0
Rear PanelAH
1
C008
66-001009-0 Clamper
1
67-065002-0
Rear PanelC
1
C009
66-001010-0 Transformer Bracket
1 R002
11-01101-03 Rocker Switch
1
C010
67-003006-0 Shielding Box
1 R003
17-07002-10
AC OutletAH
1
C011
18-32515-10 Transformer(AH)
1 R004
84-001002-0 Relief Bushing
1
18-32515-20 Transformer(C)
1 R005
15-02251-20
AC CORDC
1
C012
66-001008-0 Metal Disc
1
15-10121-10
AC CORDAH
1
C013
94-001004-2 Transformer Label
1 R006
30-63200-00 Shorting Plug
2
C014
75-065001-0 PCB Spacer
1
T001
67-065004-0
Top cover 1
F001 77-065002-0 Fascia 1
F002
66-065002-0 Subfascia
1
F003 77-001007-1 Power Button Bezel 1
F004 77-065001-0 Input Button Lozenge 1 S001
61-023106-0 Self Taping Screw STB3X6
38
F005
74-001001-1 Tone Butt
on 1 S002
61-023208-0 Self Taping Screw BTB3X8
21
F006 73-014001-1 Tone Knob 3 S003
61-023108-0 Self Taping Screw STB3X8
4
F007
73-014002-1 Volume Knob
1 S004
61-224516-0 Machine screw HM4×16
2
F008
77-001001-1 Tone Control Lozenge
1 S005
63-010410-0
Plain Washer 4
2
F009
76-003001-0 LED Lens
2 S006
63-020411-0
Spring Washer 4
2
F010
76-001001-0 IR Lens
1 S007
61-022206-6 Self Taping Screw BTB2.6X6
13
F011
76-001002-0 LED Lens
8 S008
61-022204-6 Self Taping Screw BTB2.6×4
2
F012
74-047001-0 Trio Buttons
1 S009
64-108050-0 Bolt M8×50
1
F013
74-001008-0 Quad Buttons
1 S010
63-020820-0
Spring Washer 8
2
F014 01-32509-00 IPOD BOARD PCB 1 S011
62-010802-0 Nut M8
2
F015 01-32507-00 IR BOARD ASSY 1 S012
61-084108-0 Self Taping Screw STPW4×8
2
S013
61-023206-0 Self Taping Screw BTB3X6
4
EXPLODED VIEW PARTS LIST
36
