NAD C 325BEE - Electrical Parts List

CIRCUIT NO. PART NO. DESCRIPTION
ICS
IC41, IC42, IC43 03-00082-00 TL082CP/CN/D
IC44 03-01237-00 UPC1237HA
IC45 03-01117-01
AMS1117-5.0/
LM1117MPX-5.0
IC11, IC21 03-00431-03 AZ431BZ-B
DIODES
D430 DB104
D17, D27, D101, D102,
D103, D201, D202, D203,
D37, D38, D39, D310,
D311, D312, D313, D315,
D316, D42, D43, D403,
D412, D417, D418
1N4148 (Pitch=7.5mm)
D419, D420, D423, D428 1N4148 (Pitch=10mm)
D11, D12, D21, D22 4.7V, 0.5W
D410, D411 20V, 0.5W
D49 18V, 0.5W
TRANSISTORS
Q31, Q32 31-00363-00 2SK363
Q31, Q32 or 31-00369-00 2SK369
Q31, Q32 or 31-00170-00 2SK170
QI2, Q12/1, Q44, Q45, Q47,
Q401, Q403, Q411
31-01015-00 2SA1015 GR
QI1, Q11, Q21, Q43, Q46,
Q48, Q402, Q404, Q412,
Q414, Q421
31-01815-00 2SC1815
Q117, Q217 31-00970-00 2SA970 GR
Q423, Q118, Q218 31-02240-00 2SC2240
Q422 31-00667-00 2SD667A
Q413, Q41, Q216, Q211,
Q212, Q112, Q116, Q111
31-02690-00 KSC2690AYSTU
Q42, Q213, Q210, Q110,
Q113
31-01220-00 KSA1220AYSTU
CAPACITORS
C45, C46 05-22012-00 22p, 100V, ±10%
C31, C32, C33, C34, C35,
C36, C37, C38, C39, C304,
C305, C310, C311, C312,
C313, C314, C315, C316,
C317, C318, C363, C364
05-10151-01 100p, 50V, ±10%
C343, C344, C302, C303 05-22151-01 220p, 50V, ±10%
C112, C113, C212, C213 05-47112-00 470p, 100V, ±10%
C362 05-10312-00 10n, 100V, +50%-20%
C120, C220, C434 24-22312-04 22n, 100V, ±10%
C123, C223, C3, C41, C443 24-10461-00 0.1uF, 63V, ±20%
C432 24-22461-00 0.22uF, 63V, ±20%
ELECTRIAL PARTS LIST
PCB-1: MAIN BOARD
