NAD C 545BEE - Main Assembly PCBs; Capacitors (Part 2)

- 34 -
Location Part Number Description
R12, R13, R14 4720-330A+J RMG 1/10W 33R 1% 0805
R18, R19 4723-472A+P RMG 1/16W 4.7K 1%.
R20 4723-471A+P-R RMG 1/16W 470R 1% 0603
R8 4720-102A+J RMG 1/10W 1K 1% 0805
SWITCH
S101, S102, S103, S104, S105, S107, S108, S109 5200-4905+0 Replaces 5200-4861+0-01 TACT
MISCELLANEOUS
CON101 2101-3235+0 CONNECTOR FFC 18P P1.25
L101 1808-0887+0 FERRITE BEAD 1.25X2 0805
M101, M102 4135-8341+0 HOLDER-VFD TINNED STEEL
M103 4154-4881+1 CUSHION 21X8X2
P220 7013-0800+0 WIRE-CONN 1P #18 UL1007
REM101 4151-9671+1 SPONGE 12X10X3
REMO101 4816-043T+3 IR SENSOR KSM-603TM2
VFD101 2460-2270+0/+3 DISPLAY-VFD MODULE
MAIN ASSY
C *AH SVC-C54516+MAIN PCB ASSY MAIN
C *C SVC-C54526+MAIN PCB ASSY MAIN EU
PC BOARD
H 1725-971A+0002/A PCB MAIN/KEY/SWITCH S/S
CAPACITOR
C10, C11 153F-224J+5-NLM CM 50V 0.22UF 5% RL
C13, C14 153H-224K+9-NNMJ CM 100V 0.22U 10% RB
C15 157D-106M+K-IU CE 16V 10U 20% RLT 5X11
C201 153F-152J+K-JM CM 50V 1500P 5% RLT
C203 157E-106M+K-IUE CE 25V 10U 20% RLT P5.0
C204 150F-104K+P-AC CC 50V 0.1uF 10%
C205 150F-105K+J-BD CC 50V 1U 10% 0805
C208 157D-106M+K-IU CE 16V 10U 20% RLT 5X11
C209 150F-104K+P-AC CC 50V 0.1uF 10%
C210 153Z-224K+F-6O CM 275V 0.22UF 10% RLS
C211 150T-222M+5-SK CC 400V 2200P 20% RL
C212 15CH-220J+P-AC CTC 0/60 22pF 5% 0603
C213 150F-104K+P-AC CC 50V 0.1uF 10%
C214 157F-105M+K-GII CE 50V 1UF 20% RLT 4X5
C215 150F-104K+P-AC CC 50V 0.1uF 10%
C216 157D-107M+K-IUI CE 16V 100UF 20% RLT
C217, C218 150F-104K+P-AC CC 50V 0.1uF 10%
