NAD C 545BEE - Mechanism Exploded View Parts List

- 46 -
Item Part No. Description Qty
1 ASSY, LASER, CDM DA11VZ 1
2 ASSY, MOTOR, SPINDLE 1
3 ASSY, MOTOR, SLED 1
4 CHASSIS 1
5 COVER, REAR 1
6 SAHFT, SLIDE 1
7 GEAR, MIDDLE 1
8 GEAR, DRIVE 1
9 SWITCH, LEAF 1
10 CONNECTOR-6P 1
21 MOTOR 1
31 SPECIAL SCREW M2.0uP.0 4
32 SPECIAL SCREW M2.6u6.0 1
MECHANISM EXPLODED VIEW PARTS LIST
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
NSP
