ELECTRICAL PARTS LIST
Location Part Number Description
KEY ASSY
B SVC-C54516+KEY PCB ASSY KEY p art of fascia
PC BOARD
G 1725-971A+0002/A PCB MAIN/KEY/SWITCH S/S
CAPACITOR
C1, C101 150F-104K+P-AC CC 50V 0.1uF 10%
C102 157D-106M+K-GII CE 16V 10UF 20% RLT 4X5
C103 150F-104K+P-AC CC 50V 0.1uF 10%
C104 157F-105M+K-GM CE 50V 1U 20% RLT 4X7
C105 150F-104K+P-AC CC 50V 0.1uF 10%
C106, C107 150F-470J+P-AC CC 50V 47P 5% 0603 1x2
C2, C3, C4, C5 150F-100J+P-AC CC 50V 10P 5% 0603
DIODE
D103 4840-9233+3 DIODE FAST DAN202K
Z101 4837-5B61+2 DZ 1/2W 5.45-5.73 ROHM
WAFER/SOCKET
CN102B 2102-040R+J01 WAFER 4P P2.0 90DEG
TRANSISTOR
Q102 485C-1140+3 TR DTC114YKA 2216470R2
Q3, Q4 4860-0640+3 TR 3904 HFE 100-300 SM
RESISTOR
R10 4720-330A+J RMG 1/10W 33R 1% 0805
R103 4720-471A+J RMG 1/10W 470R 1% 0805
R104, R105 4711-471A+2 RMF 1/8W 470R 1% AT
R106 4720-332A+J RMG 1/10W 3.3K 1% 0805
R107 4720-751A+J RMG 1/10W 750R 1% 0805
R108 4720-222A+J RMG 1/10W 2.2K 1% 0805
R109 4711-682A+2 RMF 1/8W 6.8K 1% AT
R11 4720-470A+J RMG 1/10W 47R 1% 0805
R110 4720-333A+J RMG 1/10W 33K 1% 0805
R111 4715-751A+2 RMF 1/4W 750R 1% AT
R112 4720-222A+J RMG 1/10W 2.2K 1% 0805
R113 4720-682A+J RMG 1/10W 6.8K 1% 0805
R115 4711-473A+2 RMF 1/8W 47K 1% AT
