NAD C 545BEE - Panel Descriptions; Rear Panel Connections; Front Panel Controls

- 5 -
1. UPGRADE PORT
2. LINE OUT
3. DIGITAL OUT (COAXIAL, OPTICAL)
4. +12V TRIGGER INPUT
5. IR INPUT
6. AC MAINS INPUT
1. STANDBY
2. STANDBY LED
3. DISC TRAY
4. OPEN/CLOSE
5. PLAY/PAUSE
6. STOP
7. RANDOM
8. REPEAT
9. DISPLAY
10. SKIP/SCAN
11. VFD
12. REMOTE SENSOR
REAR PANEL / FRONT PANEL
REAR PANEL
FRONT PANEL
12 3 45
6
12 3 4 5 6 7 8 9 10
12 11
