NAD C 545BEE - Exploded View Parts List

- 48 -
EXPLODED VIEW PARTS LIST
NOTE: - The components identified by
mark are critical for risk of fire and electrical shock.
Replace only with part number specified.
- <*AH > : USA, Canadian model only.
- <*C > : European model only.
Item Part No. Description Q’ty
0101 * Titanium SVC-C54516+FASC FRONT PANEL ASSEMBLY COMPLETE & cables 1
0101 * Grey SVC-C54517+FASC FRONT PANEL ASSEMBLY COMPLETE & cables 1
0102 * Titanium 2447-7202+0 BUTTOM TRIO INPUT FRONT NSP 3
0102 * Grey 2447-7201+0 BUTTOM TRIO INPUT FRONT NSP 3
0104 * Titanium 2447-7302+0 BUTTON-POWER NSP 1
0104 * Grey 2447-7301+0 BUTTON-POWER NSP 1
0106 3717-6811+0 LENS-DISPLAY NSP 1
0107 * Titanium 3717-7011+0 LENS FRONT NSP 1
0107 * Grey 3717-7012+0 LENS FRONT NSP 1
0108 2954-3008+3000 SCREW B-TITE BIND M3X8 13
0201 * AH 1402-352P+2 CHASSIS MAIN - For US Ver. 1
0201 * C 1402-352N+2 CHASSIS MAIN - For EU Ver. 1
0202 4104-3721+0 TRANSFORMER BRACKET 1
0203 * Titanium 1468-4002+0 CD DOOR 1
0203 * Grey 1468-4001+0 CD DOOR 1
0204 SVC-C54516+MECH DECK-CD CDM DA11VZ 1
SVC-C56516+MECH
0206 4135-8331+1 STRIP-TOP 1
0207 4135-8351+0 BRACKET-CD 2
0208 2904-3005+0000 SCREW M3X5 10
0209 2904-3010+0000 SCREW M3X10 (BLK) 4
0210 * Titanium 2904-3005+4000 SCREW M3X5 6
0210 * Grey 2904-3005+3000 SCREW M3X5 6
0212 2904-3008+3000 SCREW M3X8 (BLK) 2
0215 2900-4006+3010 SCREW M4X6 4
0218 2113-3317+0 SOCKET AC 2PIN 250V 7A 1
0219
1806-4047+0000 TRANSFORMER PWR 1
0220 & 0221 SVC-C54516+FOOT PLASTIC FOOT W/RUBBER ATTACHED 4
0222 2904-3005+3000 SCREW M3X5 BINDING (BLK) 4
0223 2904-3006+0000 SCREW M3X6 11
0301 * Titanium 1402-3532+0 TOP COVER 1
0301 * Grey 1402-3534+0 TOP COVER 4
0302 * Titanium 2900-4006+2010 SCREW M4X6 4
0302 * Grey 2900-4006+3010 SCREW M4X6 4
0303 * Titanium 2954-3010+4000 SCREW B-TITE BIND HEAD 1
0303 * Grey 2954-3008+3000 SCREW B-TITE BIND HEAD 4
A SVC-C54516+SERVO PCB ASSY SERVO 1
B SVC-C54516+KEY PCB ASSY KEY NSP PART OF 0101 ABOVE 1
C * AH SVC-C54516+MAIN PCB ASSY MAIN 1
C * C SVC-C54526+MAIN PCB ASSY MAIN 1
D SVC-C54516+SW PCB ASSY SWITCH NSP PART OF 0101 ABOVE 1
