NAD C 545BEE - Electrical Parts List; Transistors (Part 2); Fuses

- 37 -
Location Part Number Description
Q6 4802-02K0+3 DIODE SW 80V 300MA
WAFER/SOCKET
J209 2101-9400+0 JM2422-3M WAFER
J215 2101-3149+0 CONNECTOR FFC 15P P1.25
J220 2102-030S+003 3P ST.WAFER P=2.0
J221 2102-080S+003 8P ST. WAFER P=2.0
JACK/SOCKET
J214 2113-2036+0 PHONE JACK D315 BK
RCA202 2113-3203+0 SOCKET RCA COAXAL
COIL
L2 1808-0680+0 FERRITE BEAD INDUCTOR
L202 1806-4041+0000 CHOKE COIL 7.7MH 10%
L203 1807-100Q+P FERRITE COIL 10UH 15%
CRYSTAL
X201 2300-2990+0 X’TAL 8MHZ HC-49/U-S
X202 2300-3306+0 CRYSTAL QUARTZ 32.768KHZ
RELAY
RL202 4500-0762+0 RELAY 5VDC 10A SPDT
TRANSISTOR
Q1, Q2 4860-0640+3 TR 3904 HFE 100-300 SM
Q205 4860-0700+K TR 2SC1815-GR(TE2/F/T) R
Q206 4851-4570+5 TR PNP 2SB1457 TO-92 RL
Q207 4860-0700+K TR 2SC1815-GR(TE2/F/T) R
Q208, Q209 4860-2390+K TR 2N3906 RLT TO92
Q210, Q211, Q212, Q213 4860-1780+K TR 2SD655F HFE600-1200
Q215 485B-9080+3 TR PNP 2SB908 2000
Q216 4852-458G+K TR 2SC2458-GR(F, T) RLT
U205 4860-8050+0 REG NJM7809FA-#ZZZB
FUSE
FC201 *C
5120-0050+0 FUSE T1.6A/250V 5X20
FC201 *AH
5120-0052+0 FUSE T1.6A 250V 5X20
FC202, FC204, FC205 *C
5120-0018+0 FUSE T1A 250V 5X20
FC202, FC204, FC205 *AH
5120-0020+0 FU T1A 250V UL/CSA 5X20
FC203 *C
5120-0035+0 FU T100MA 250V
FC203 *AH
5120-0036+0 FUSE 250V 100MA T 5X20
