NAD C 565BEE - Electrical Parts List

- 35 -
ELECTRICAL PARTS LIST
Location Part Number Description
LED ASSY
E SVC-C56516+LED PCB ASSY LED part of fascia
PC BOARD
E 1725-982A+0001 PCB MAIN/VFD/USB/PWR/VOL D
WAFER/SOCKETS
CON141A 2102-040R+J01 WAFER 4P P2.0 90DEG
TRANSISTOR
Q141 4858-46B0+3 TR BC846B SOT23 PHILIPS
RESISTOR
R141 4723-472A+P RMG 1/16W 4.7K 1%.
R142 4723-122A+P RMG 1/16W 1.2K 1% 0603
R160 4723-431A+P RMG 1/16W 430R 1% 0603
SWITCH
S109 5200-4905+0 Replaces 5200-4861+0-01 TACT
LED
D141 3700-2858+AB LED SP 5X5XL0.5 AM/BU
MAIN ASSY
A *AH SVC-C56516+MAIN PCB ASSY MAIN
A *C SVC-C56526+MAIN PCB ASSY MAIN
PC BOARD
A 1725-982A+0001 PCB MAIN/VFD/USB/PWR/VOL
CAPACITOR
C200 157D-106M+K-IUE CE 16V 10U 20% RLT 5X11
C201 150F-104K+P-AC CC 50V 0.1uF 10%
C202 150F-104J+P-AC CC 50V 0.1U 5% 0603
C203 150F-104K+P-AC CC 50V 0.1uF 10%
C204, C205 157D-106M+K-IUE CE 16V 10U 20% RLT 5X11
C206 150F-104K+P-AC CC 50V 0.1uF 10%
