NAD C 565BEE - Exploded View Parts List

- 54 -
EXPLODED VIEW PARTS LIST
Item Part No. Description Q’ty
0101 * Grey SVC-C56517+FASC PANEL-FRONT AL fascia assembly with cables 1
0101 * Titanium SVC-C56516+FASC PANEL-FRONT AL fascia assembly with cables 1
0102 * Grey 1468-5302+1 FRAME-FRONT NSP 1
0102 * Titanium 1468-5301+1 FRAME-FRONT NSP 1
0103 * Grey 3717-7013+0 FRONT LENS NSP 1
0103 * Titanium 3717-7011+0 FRONT LENS NSP 1
0104 * Grey 4135-8803+0 PLATE-LEFT NSP 1
0104 * Titanium 4135-8801+0 PLATE-LEFT NSP 1
0105 * Grey 4135-8804+0 PLATE-RIGHT NSP 1
0105 * Titanium 4135-8802+0 PLATE-RIGHT NSP 1
0106 2904-3006+0000 SCREW M3X6 19
0107 * Grey 2444-8402+0 KNOB-VOL/SELECT NSP 1
0107 * Titanium 2444-8401+0 KNOB-VOL/SELECT NSP 1
0108 2447-8801+0 BUTTON TRIO-INPUT NSP 3
0109 * Grey 2445-3801+0 BUTTON-SKIN NSP 8
0109 * Titanium 2445-3802+0 BUTTON-SKIN NSP 8
0110 * Grey 2444-8602+0 BUTTOM-POWER NSP 1
0110 * Titanium 2444-8601+0 BUTTOM-POWER NSP 1
0111 4135-7521+0 BRACKET-PHONE NSP 2
0115 3717-6811+0 LENS-DISPLAY NSP 1
0116 2954-3008+3000 SCREW 3X8 TAP 17
0201 * C 1402-352N+2 CHASSIS MAIN 1
0201 * AH 1402-352Q+2 CHASSIS MAIN 1
0202 4104-3721+0 TRANSFORMER BKT 1
0203 * Grey 1468-4001+0 CD DOOR 1
0203 * Titanium 1468-4002+0 CD DOOR 1
0204 SVC-C56516+MECH DECK-CD CDM DA11VZ 1
0206 4135-8332+1 STRIP-TOP 1
0207 4135-8351+0 BRACKET-CD 2
0208 2904-3005+0000 SCREW M3X5 10
0209 2904-3010+0000 SCREW M3X10 4
0210 * Grey 2904-3005+3000 SCREW M3X5 2
0210 * Titanium 2904-3005+4000 SCREW M3X5 2
0212 2901-2605+3000 SCREW M2.6X5 2
0212 2904-3008+3000 SCREW M3X8 2
0213 2640-3022+0542 NUT HEX M3 2
0215 2900-4006+3010 M4X0.5PX6 4
0217 * Grey 2904-3005+3000 SCREW M3X5 4
0217 * Titanium 2904-3005+4000 SCREW M3X5 4
0219
1806-4047+0000 TRANSFORMER PWR 1
0220-0221 SVC-C56516+FOOT FOOT-BOTTOM & CUSHION 4
