NAD C 565BEE User Manual

- 6 -
7
6
6
5
4
3
1
2
DISASSEMBLY INSTRUCTIONS
1. Remove machine screws M 4.0 x 6.0 ( 1 to 4 ) from the side panels.
Remove tapping screw 3.0 x 8.5 ( 5 )from the back panel.
Refer to Figure No.1.
Figure No.1
2. Pull both sides of the TOP COVER slightly outwards 6 and tilt approx. 35˚ and then remove
in the direction as indicated by the arrow 7 . Refer to Figure No.2.
Figure No.2.

NAD C 565BEE Specifications

General

Frequency range	20 - 20000 Hz
Audio formats supported	MP3, WMA
Signal-to-Noise Ratio (SNR)	118 dB
Total Harmonic Distortion (THD)	0.01 %
CD changer	No
Device type	Personal CD player
MP3 playback	Yes
Product color	Graphite
Disc loading type	Tray
Channel separation	90 dB
Volume control	Digital
USB 2.0 ports quantity	1
Package weight	6600 g

Weight and Dimensions

Depth	285 mm
Width	435 mm
Height	70 mm
Weight	5200 g
