NAD C 565BEE - Panel Layouts; Rear Panel Connections; Front Panel Controls

- 5 -
1. LINE OUT
2. RS232
3. DIGITAL AUDIO IN (OPTICAL)
4 DIGITAL OUT (COAXIAL, OPTICAL)
5. +12V TRIGGER INPUT
6. IR IN
7. AC MAINS INPUT
1. STANDBY BUTTON
2. STANDBY LED
3. DISC TRAY
4. STOP/OPEN
5. SOURCE
6. SRC
7. RANDOM
8. REPEAT
9. DISPLAY
10. SCAN
11. USB INPUT
12. PLAY/PAUSE/SKIP
13. VFD
14. REMOTE SENSOR
REAR PANEL / FRONT PANEL
REAR PANEL
FRONT PANEL
234 5 6 71
12 3 4 5 6 7 8 9 12
14 13
10 11
