52
CONNECTOR-2
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
J7001B
to MAIN (J7001A)
1 2 3 4 5 6 7 8
J8201B to PSU-ISC (J8201A)
1 2 3 4
J8002B to PSU-STD (J8002A)
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
J2301B
to TRIGGER (J2301A)
1 2 3 4 5 6 7 8 9
10
J8202B
to PSU-ISC (J8202A)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26
J2007B
To MCU (J2007A)
AC4.8V2 AC4.8V1 AC8.8V4 AC8.8V4 AC8.8V3 AC8.8V3 AC8.8V2 AC8.8V2
+13V
DGND
+12V_D
DGND
DAB_I N
DAB_RXD_5V
DAB_TXD_5V
+5V_K
TRIG_OUT_3 TRIG_OUT_2 TRIG_OUT_1
TRIG_IN
IR_R_MIX
XM_PWR
IR_O_2
IR_O_1
232_RXD
232_TXD
AUTO/OFF
S_CLIP_IND
SC_2 SC_1
AC4.8V2 AC4.8V1 AC8.8V4 AC8.8V4 AC8.8V3 AC8.8V3 AC8.8V2 AC8.8V2 AC8.8V1 AC8.8V1 AC17.6V2 AC17.6V2 AGND AGND AC17.6V1 AC17.6V1 +12.3V
POWER_ON
+12.3V
AC8.8V1 AC8.8V1
AC17.6V2 AC17.6V2
AGND AGND
AC17.6V1 AC17.6V1
AC29V
AC29V
IR_R_MIX TRIG_IN TRIG_OUT_2 TRIG_OUT_1 DGND TRIG_OUT_3 +5V_K +12V_D +5V_V +12V_D +13V +13V POWER_ON DAB_TXD_5V DAB_RXD_5V DAB_I N SC_1 SC_2 S_CLIP_IND AUTO/OFF 232_TXD 232_RXD IR_O_1 IR_O_2 XM_PWR
IR_R
IR_R
+5.3V
+5.3V DGND
+5V_V
