NAD T 775 - Page 56

54
SPEAKER
CENTER SPK
FRONT RIGHT SPK_A
FRONT LEFT SPK_A
SURR LEFT SPK
SURR RIGHT SPK
BACK SURR LEFT SPK
FRONT RIGHT SPK_B
FRONT LEFT SPK_B
SPEAKER A SPEAKER B
BACK SURR RIGHT SPK
C9201
3300p
C9202
3300p
C9203
3300p
C9204
3300p
C9205
3300p
C9206
3300p
C9209
3300p
C9208
3300p
C9207
3300p
J5802B_2 J5403B_2 J5403B_3 J5802B_3 J5403B_4 J5802B_4 J5403B_5 J5802B_1 J5403B_1
J8106B_1 J8105B_1 J8105B_2 J8106B_2 J8105B_3 J8106B_3 J8105B_4
1
M9201
1
M9211
1
M9212
1
M9202
1
M9213
1
M9203
1
M9204
1
M9214
1
M9215
1
M9205
1
M9206
1
M9216
1
M9217
1
M9207
1
M9208
1
M9218
1
M9219
1
M9209
FL_A FR_A C SL SR BSL BSR FL_B FR_B
FL_GND
FR_GND
C_GND
SL_GND
SR_GND
BSL_GND
BSR_GND
