80
SMD INDUCTORS
L1018*AH 07-007-0017-90 IND 2.7uH SMD 10% 0805 CI201209-
2R7KG
L1020 L1021 L1022 L1023 07-007-0035-90 IND SMD 1.5uH 10% 0805 CI2012-1R5K
L1001-1004 10-009-0005-90 DIGITAL AUDIO INTERFACE SIGNAL
TRANSFORMER ER9.5 225uH
RA070228-1
SMD OSCILLATORS
X1001C 14-004-0020-90 CRYSTAL OSCILLATOR 24.576MHz
3.3V 50ppm 30pF
X1003*AH 14-004-0024-90 CRYSTAL OSCILLATOR 45.1584MHz
3.3V 50ppm 30pF
COMPOSITE VIDEO BOARD
PCB ASSEMBLY 50-920-0785-90 T175/T775/T785 COMPOSITE VIDEO
ASSY
RCA JACKS
M4101-M4108 15-003-0032-90 RCA JACK 1 YELLOW & S-VIDEO PCB
MOUNT W/COVER DASW-8.4-11
M4109 15-003-0037-90 RCA JACK 1 Y PCB MOUNT GOLD W/
COVER
SMD ICS
U4103-4106 01-012-0062-00 IC LOGIC 8-CHANNEL ANALOG MUX/
DEMUX SMD 74HC4051D
U4107 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
U4101-4102 01-026-0001-90 IC VIDEO 3-CHANNEL 75 OHM DRIVER
SSOP BA7660FS
SMD RESISTORS
R4125 R4134 02-007-0042-00 RES SMD 1K OHM 0603 5%
R4149-4150 02-007-0089-00 RES. SMD 0 OHM +/-5% 1/10W 0805
R4113-4114 R4107-4108 R4142 02-007-0141-00 RES SMD 100 OHM 0603 5%
R4121 R4122 R4133 R4132 02-007-0146-00 RES SMD 47 OHM 0603 5%
R4119 R4120 R4151 R4152 02-007-0151-00 RES SMD 10 OHM 0603 5%
R4143-4144 R4146-4147 02-007-0157-00 RES SMD 10K OHM 0603 1%
R4135 R4126 R4145 R4148 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R4123 R4161 R4162 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R4156 R4157 02-007-0289-00 RES SMD 68 OHM +/-1% 1/16W 0603
R4139-4140 R4137-4138 02-007-0352-00 RES SMD 470K OHM 5% 1/16W 0603
R4101-4106 R4109-4112 R4115-R4118 02-007-0357-00 RES SMD 75 OHM 5% 1/16W 0603
R4124 R4127-4131 R4136 R4160
SMD CAPACITORS
C4118 C4120 C4135 C4138 C4153 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C4142-4143 03-009-0113-00 CAP CER SMD 10nF 50V 10% X7R 0603
C4152 03-009-0136-00 CAP ELEC SMD 10uF 16V +/-20% 4X5.4
C4132 03-009-0138-00 CAP ELEC SMD 1000uF 10V +/-20%
10x10.5
C4101-4107 C4109-4111 C4113-4115 03-009-0141-00 CAP ELEC SMD 2.2uF 50V +/-20% 4x5.4
C4121-4123 C4125 C4127 C4147
C4134 C4137 C4119 C4117 C4141 C4131 03-009-0143-00 CAP ELEC SMD 47uF 50V +/-20%
6.3X7.7
C4112 C4108 C4116 C4124 C4126 03-009-0144-00 CAP ELEC SMD 470uF 16V +/-20%
C4128-4130 C4139-4140 C4145-4146 10X10.5
