NAD T 775 - Page 83

81
SMD DIODES
D4101-4106 04-006-0021-90 SMD Diode LL4148 SOD80
SMD TRANSISTORS
Q4102,Q4104,Q4107-4108,Q4113-4114 05-004-0017-00 SMD Transistor 2SC4695 NPN SOT-23
Q4101,Q4103,Q4109-4112,Q4118 05-004-0034-90 TRANSISTOR 2SA1037AKS PNP HFE
270-560 140MHz SMD SMT3
Q4105-4106,Q4115-4116 05-004-0036-90 TRANSISTOR SS NPN HFE20 250MHz
DTC123EKAT146
KEYBOARD
PCB ASSEMBLY 50-922-0765-90 T765/T775/T785 KEYBOARD ASSY
CAPACITORS
C2208 03-002-0137-00 CAP ELEC SS 1uF 50V 20% 85C RAD
HEIGHT= 7mm MAX
C2211 03-002-0143-00 CAP ELEC SS 47uF 16V 20% 85C RAD
HEIGHT = 7mm MAX
IR
D2202 04-009-0003-90 IR RX 37.9kHz SHIELD RT
FM-6038TM2-5AN
ENCODER
M2201 06-006-0009-90 ENCODER ROTATRY STD L=20MM
VERT. W/O CLICK
TACT SWITCH
S2201-S2218 11-007-0061-90 SW TACT NO 1P1T 50mA/12V VER
H=5mm LUG FUNG
VFD
VD2201 12-005-0029-90 VFD 16-BT-130-GINK T775
LED
D2201 12-006-0125-90 LED RED-ORN-BLU CIRCULAR
5X8.7MM BL-BUBJFB52C4V-1 COMMON
ANODE
SMD IC
U2201 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
SMD RESISTORS
R2201 R2237-R2239 02-007-0042-00 RES SMD 1K OHM 0603 5%
R2204 02-007-0136-00 RES SMD 33K OHM 0603 5%
R2202 02-007-0139-00 RES SMD 4.7K OHM 0603 5%
R2232-2233 02-007-0141-00 RES SMD 100 OHM 0603 5%
R2210 02-007-0151-00 RES SMD 10 OHM 0603 5%
R2207 R2212-2216 R2230-2231 02-007-0157-00 RES SMD 10K OHM 0603 1%
R2203 R2211 R2234-2236 R2240 R2241 02-007-0292-00 RES SMD 2.2K OHM 1% 1/16W 0603
R2205 R2209 02-007-0294-00 RES SMD 470 OHM 5% 1/16W 0603
R2206 R2208 02-007-0315-00 RES SMD 22 OHM 5% 1/4W 1206
SMD CAPACITORS
C2201-2204 C2207 C2210 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C2205-2206 03-009-0111-00 CAP CER SMD 100pF 50V 10% X7R
0603
