82
C2212 03-009-0119-00 CAP CER SMD 4.7nF 50V 10% X7R 0603
SMD DIODES
D2204-2209 04-006-0021-90 SMD Diode LL4148 SOD80
D2203 04-007-0031-00 DIODE ZENER SMD 6.2V 500mW 5%
SOD123 MMSZ5234B
SMD TRANSISTORS
Q2201 05-004-0030-90 XTR 2SD1918 NPN POWER 160V/1.5A
80MHz HFE 120-390 SMD
Q2202-Q2204 Q2205 Q2206 05-004-0037-90 TRANSISTOR SS PNP HFE30 250MHz
SPT DTA114EKAT146
JUMPERS
JMP1 JMP3 JMP5-12 JMP16 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP20-23 JMP26-29 JMP32-34
JMP36 JMP38 JMP43
JMP2 JMP4 JMP13-15 JMP17-19 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
JMP24-25 JMP30-31 JMP35 JMP37 than 14mm
JMP39-41
PRE-OUT BOARD
PCB ASSEMBLY 50-924-0765-90 T765/T775/T785 PRE-OUT ASSY
RCA JACKS
M6502 M6504 15-003-0022-90 RCA JACK 2 B/B PCB MOUNT GOLD
RS-213G-02(W)
M6505 15-003-0036-90 RCA JACK 1 BLACK PCB MOUNT GOLD
W/O COVER
M6501 M6503 15-003-0046-90 RCA JACK 6 W-W-W/R-R-R PCB
MOUNT GOLD W/O SHIELD
SMD ICS
U6901 01-012-0065-00 IC LOGIC 8-STAGE SHIFT-AND-STORE
BUS REGISTER SMD SO16 HEF4094BT
U6501 U6601 U6701 U6801 01-014-0041-00 IC AUDIO LOW NOISE OP-AMP SMD
NJM5532M
SMD RESISTORS
R6901-6902 R6907-6908 R6913-6914 02-007-0042-00 RES SMD 1K OHM 0603 5%
R6919-6920
R6971-6979 02-007-0089-00 RES SMD 0 OHM 1/8W 0805 5%
R6924 R6917-6918 R6905-6906 02-007-0136-00 RES SMD 33K OHM 0603 5%
R6911-6912 R6923
R6502 R6602 R6702 R6802 R6513 02-007-0140-00 RES SMD 47K OHM 0603 5%
R6613 R6713 R6813 R6524 R6624
R6724 R6824 R6535 R6635 R6735
R6632 R6531-6532 R6642-6643 R6647 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R6648 R6610 R6509-6510 R6709-6710
R6609 R6620-6621 R6720-6721
R6731-6732 R6747 R6748 R6521
R6742-6743 R6542 R6809-6810 R6520
R6543 R6547 R6548 R6820-6821
R6831-6832 R6848-R6850 R6631
