84
SMD DIODES
D6901-6904 04-006-0019-00 DIODE RECT 1A/400V DO-214AC SMD
GS1G M4 GS1G
D6910-6915 04-006-0021-90 SMD DIODE LL4148 SOD80
D6501-6504 D6601-6604 D6701-6704 04-007-0039-90 DIODE ZENER SMD 12V 500mW 5%
D6801-6804 SOD123 MM1Z12
SMD TRANSISTORS
Q6501-6504 Q6506-6509 Q6601-6604 05-004-0017-00 SMD Transistor 2SC4695 NPN SOT-23
Q6606-6609 Q6701-6704 Q6706-6709
Q6801-6804 Q6806-6807
Q6505 Q6510 Q6605 Q6610 Q6705 05-004-0037-90 TRANSISTOR SS PNP HFE 30 250MHz
Q6710 Q6805 Q6808 Q6810 SPT DTA114EKAT146
SMD INDUCTORS
L6505 L6507-L6508 L6510-L6511 07-007-0019-90 IND SMD 10uH +/-10% 0805 TAPE L6-
513-L6514 L6516 L6518 YT201212T-100K-S
ISC & SECONDARY BOARD ASSY
PCB ASSEMBLY 50-952-0765-90 T765/T775 ISC & SECONDARY ASSY
CAPACITORS
C8101-8104 03-002-0098-00 E CAP 12000uF/80V-40+80 ±20% D=35
H=50mm
C8202-8204 C8206-8210 03-002-0129-00 CAP ELEC SS 10uF 16V 20% 85C RAD
HEIGHT =7mm MAX
C8211-8219 03-004-0031-00 MPF CAP 104J/63V 5% Mini Box
7x2.5x6.5mm P=5
DIODES
D8101-8102 04-005-0015-00 Bridge Rectifier BR254W 25A/400V BR-
25W
D8203-8206 04-001-0046-00 DIODE RECT 12A/600V TO-220 TYN612
D8201-8202 04-005-0021-90 DIODE BRI 10A/400V KBK10G
D8207-8208 D8211-8212 04-001-0001-00 Diode 1N4148 DO-35 0.15A/100V Signal
Switching Diode
D8209-8210 04-002-0049-90 DIODE ZENER BZX55 12V 1/2W 5%
DO35 BZX55-C12V
RESISTORS
R8241-8244 02-005-0062-00 RES RN 0.22 OHM 5% 5W SIL 3 PIN
COMMAND PIN2 WW
R8245-8246 02-010-0001-00 RES MO 4K OHM 5% 5W
R8247-8253 02-010-0011-00 RES MO 0.22 OHM 5% 1/2W
TRANSISTORS
Q8201 Q8203 Q8205 Q8208 Q8210 05-001-0072-00 Transistor SS NPN HEF 100 200MHs
Q8212 TO-92 C1815Y
Q8202 Q8204 Q8209 Q8211 05-001-0080-00 TRANSISTOR SS PNP HFE 100 200MHz
TO-92 A1015Y
Q8206-8207 Q8213-8214 05-001-0083-00 TRANSISTOR SS PNP HFE 280-560
110MHz 2SA1016KG-AA
VARIABLE RESISTORS
R8214 R8217 06-004-0017-90 VR SEMI-FIXED RESISTOR CF 50K
OHM 30% B 6mm HOR
