NAD T 775 - Page 87

85
SMD ICS
U8201 01-014-0041-00 IC AUDIO LOW NOISE OP-AMP SMD
NJM5532M
SMD RESISTORS
R8209 R8203 02-007-0042-00 RES SMD 1K OHM 0603 5%
R8225 R8230 02-007-0139-00 RES SMD 4.7K OHM 0603 5%
R8206 R8212 R8215 R8218 02-007-0157-00 RES SMD 10K OHM 0603 1%
R8201-8202 R8207-8208 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R8205 R8204 R8210-8211 02-007-0292-00 RES SMD 2.2K OHM 1% 1/16W 0603
R8216 R8213 02-007-0333-00 RES SMD 680K OHM 5% 1/16W 0603
SMD CAPACITORS
C8201 C8205 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
JUMPERS
JMP4 JMP7-JMP16 JMP18-20 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP1 JMP2 JMP3 JMP5-6 JMP17 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
JMP21-24 than 14mm
SPEAKER BOARD
PCB ASSEMBLY 50-927-0775-90 T775/T785 SPEAKER ASSY
SPEAKER TERMINALS
16-001-0439-90 BINDING POST BASE 4P BLACK
16-003-0585-90 BINDING POST KNOB ASSY BLACK
16-003-0586-90 BINDING POST KNOB ASSY RED
TRIGGER BOARD
PCB ASSEMBLY*AH 50-930-0765-90 T765/T775/T785 AH TRIGGER ASSY
PCB ASSEMBLY*C,CT 50-947-0765-90 T765/T775/T785 C/CT TRIGGER ASSY
CAPACITORS
C2314 C2316 C2325 C2328 C2329 03-002-0129-00 CAP ELEC SS 10uF 16V 20% 85C RAD
HEIGHT =7mm MAX
C2318-2320 C2324 03-002-0137-00 CAP ELEC SS 1uF 50V 20% 85C RAD
HEIGHT= 7mm MAX
C2311*C,CT 03-002-0143-00 CAP ELEC SS 47uF 16V 20% 85C RAD
HEIGHT = 7mm MAX
SLIDE SWITCHES
S2301-S2302 11-002-0042-90 SW SLIDE 2P2T RIGHT L=9
JACKS
M2301-M2304 15-002-0030-90 PHONE JACK X2 BLACK PCB MOUNT
3.5mm RIGHT ANGLE
SCJ351P00XS0B00G
M2306*C,CT 15-017-0003-90 DIN MINI JACK BLACK PCB MOUNT W/
COVER RIGHT ANGLE 9 PINS
XM CONNECTOR
M2307*AH 16-001-0440-90 XM 4 PINS SMALL CONNECTOR B
TYPE 2.4mm PCB MOUNT
DAB CONNECTOR
M2306*C,CT 15-017-0003-90 DIN MINI JACK BLACK PCB MOUNT W/
COVER RIGHT ANGLE 9 PINS
