NAD T 775 - Page 88

86
DB9 CONNECTOR
M2305 16-002-0200-90 DB9 FEMALE CONNECTOR PCB
MOUNT RIGHT ANGLE
COILS
L2301-L2303 07-002-0154-90 COIL 15uH ±30% W/BEAD RH3.5 X 1.3 X
3-4.5Ts-A
SMD ICS
U2304*C,CT 01-004-0056-90 IC VOLT REG. LOW DROPOUT 3.3V 1A
SOT-223 LM1117S-3.3
U2303 01-012-0075-90 IC 74HC86D LOGIC QUAD 2-INPUT
EXCLUSIVE-OR GATE SMD 14 PINS
SOIC
D2308*AH 01-012-0076-90 IC CM1213 8-Channel Low Capacitance
ESD Protection Arrays CM1213-08MR
U2301 01-015-0005-90 IC RS-232 DRIVERS AND RECEIVERS
ST232BDR
U2302 01-028-0003-90 IC TPS2011A 8-SOIC LEAD FREE
SMD RESISTORS
R2330*C,CT 02-007-0042-00 SMD RES 1K OHM 0603 5%
R2341 02-007-0127-00 RES SMD 15K OHM 0603 5%
R2309 02-007-0136-00 RES SMD 33K OHM 0603 5%
R2329 R2348*C,CT 02-007-0139-00 SMD R 4.7K OHM 0603 5%
R2320-2321 02-007-0146-00 RES SMD 47 OHM 0603 5%
R2324 02-007-0149-00 RES SMD 1.8K OHM 0603 5%
R2304 R2308 R2313 R2316 R2319 02-007-0157-00 RES SMD 10K OHM 0603 1%
R2322-2323 R2344-2346 R2351
R2356 02-007-0208-00 RES SMD 0 OHM 1/8W 1206 5%
R2310 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R2331-2332*AH R2339 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R2303 02-007-0292-00 RES SMD 2.2K OHM 1% 1/16W 0603
R2311-2312 R2314-2315 R2317-2318 02-007-0323-00 RES SMD 3.3 OHM 5% 1W 2512
R2354 02-007-0343-00 RES SMD 22 OHM 5% 1/10W 0805
R2305-2307 02-007-0356-00 RES SMD 560 OHM 5% 1/10W 0805
R2358 R2359 02-007-0396-00 RES SMD 100 OHM +/-5% 1W 2512
SMD CAPACITORS
C2305-2308 C2310*C,CT C2315 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C2326-2327
C2302-2304 03-009-0078-00 CAP CER CAP 47pF/50V 10% NPO 0603
C2317 03-009-0111-00 CAP CER SMD 100pF 50V 10% X7R
0603
C2301 03-009-0113-00 CAP CER SMD 10nF 50V 10% X7R 0603
SMD DIODES
D2301-2306 D2307*C,CT 04-006-0021-90 SMD Diode LL4148 SOD80
SMD TRANSISTORS
Q2309 Q2311 Q2313 05-004-0031-90 XTR 2SB1275 PNP POWER 160V/1.5A
50MHz HFE 82-180 SMD
Q2301 Q2303 Q2305 Q2307-2308 Q2310 05-004-0035-90 TRANSISTOR SS NPN HFE30 250MHz
Q2312 Q2314 Q2321 Q2316-2319*C,CT SPT DTC114EKAT146
Q2302 Q2304 Q2306 Q2320 05-004-0037-90 TRANSISTOR SS PNP HFE 30 250MHz
SPT DTA114EKAT146
