JUMPERS
JMP3 JMP6 JMP14 JMP19-21 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP34 JMP41-42
JMP1-2 JMP4-5 JMP7-13 JMP15-18 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
JMP22-33 JMP35-40 JMP43-44 than 14mm
VIDEO 6 BOARD
PCB ASSEMBLY 50-931-0765-90 T765/T775/T785 VIDEO-6 ASSY
CAPACITORS
C9309 C9307 C9315 C9320-9321 03-002-0073-00 E CAP 22uF/16VP=1.5 D=4.2 H=7.6
C9302-9305 C9314 03-002-0140-00 CAP ELEC SS 2.2uF 50V 20% 85C RAD
P=1.5
FIBRE OPTIC
M9301 04-009-0004-90 FIBRE OPTIC RECEIVING UNIT 700nm
JSR1164-D
JACKS
M9302 15-002-0028-90 PHONE JACK 1 BLACK PCB MOUNT
3.5mm RIGHT
M9308 15-002-0029-90 PHONE JACK D6.3 1 PCB MOUNT
GOLD
M9305 15-003-0048-90 RCA JACK 1 YELLOW PCB MOUNT
GOLD RCA-105BL1-13Z1
M9306 15-003-0049-90 RCA JACK 1 RED PCB MOUNT GOLD
RCA-105AL1-14Z1
M9307 15-003-0050-90 RCA JACK 1 WHITE PCB MOUNT GOLD
RCA-105AL1-12Z1
M9304 15-017-0001-90 DIN JACK 1 BLACK PCB MOUNT
MD-113
SMD IC
U9301 01-014-0041-00 IC AUDIO LOW NOISE OP-AMP SMD
NJM5532M
SMD RESISTORS
R9333 02-007-0042-00 RES SMD 1K OHM 0603 5%
R9301 02-007-0134-00 RES SMD 4.7 OHM 0805 5%
R9307 R9310 R9311 R9330-9332 02-007-0136-00 RES SMD 33K OHM 0603 5%
R9320 R9323 R9327 02-007-0139-00 RES SMD 4.7K OHM 0603 5%
R9313 02-007-0143-00 RES SMD 18K OHM 0603 5%
R9319 R9326 02-007-0157-00 RES SMD 10K OHM 0603 1%
R9317 02-007-0160-00 RES SMD 43K OHM 0603 5%
R9325 R9324 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R9305 R9308 R9328 R9329 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R9314,R9316 02-007-0292-00 RES SMD 2.2K OHM 1% 1/16W 0603
R9321-9322 02-007-0294-00 RES SMD 470 OHM 5% 1/16W 0603
R9318 02-007-0319-00 RES SMD 300 OHM 5% 1/16W 0603
R9302-9304 02-007-0357-00 RES SMD 75 OHM 5% 1/16W 0603
SMD CAPACITORS
C9301 C9316-9317 C9323-9324 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C9306 C9308 C9318-9319 03-009-0111-00 CAP CER SMD 100pF 50V 10% X7R
0603
C9310-9311 03-009-0112-00 CAP CER SMD 1nF 50V 10% X7R 0603
