NAD T 775 - Page 90

88
C9326 03-009-0113-00 CAP CER SMD 10nF 50V 10% X7R 0603
C9313 03-009-0114-00 CAP CER SMD 220pF 50V 10% X7R
0603
C9322 03-009-0116-00 CAP CER SMD 33pF 50V 10% X7R 0603
C9325 03-009-0127-00 CAP CER SMD 1uF 16V +80/-20% Y5V
0805
SMD TRANSISTORS
Q9303-9304 Q9305 05-004-0017-00 SMD Transistor 2SC4695 NPN SOT-23
Q9301-9302 05-004-0037-90 TRANSISTOR SS PNP HFE 30 250MHz
SPT DTA114EKAT146
JUMPERS
JMP3-4 JMP6-8 JMP10 JMP14-15 JMP22 17-016-0077-00 Jumper wire Dia. 0.5mm L=52.0mm
JMP1 JMP5 JMP9 JMP11-13 JMP16-21 17-016-0080-90 Jumper Wire Dia. 0.5mm For L Smaller
JMP23 than 14mm
COMPONENT VIDEO BOARD
PCB ASSEMBLY 50-932-0775-90 T175/T775/T785 COMPONENT VIDEO
ASSY
JACKS
M4001 15-002-0035-90 PHONE JACK 1 GREEN PCB MOUNT
3.5mm RIGHT
M4011,M4012 15-003-0033-90 RCA JACK 6 R-BL-G/R-BL-G PCB
MOUNT GOLD
SMD ICS
U4002-4003 01-012-0067-00 IC LOGIC ANALOG MULTIPLEXER/DE
MULTIPLEXER SMD SOIC-16
74HC4052D
U4001 01-026-0001-90 IC VIDEO 3-CHANNEL 75 OHM DRIVER
SSOP BA7660FS
SMD RESISTORS
R4021,R4023,R4024 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R4004-4006 02-007-0352-00 RES SMD 470K OHM 5% 1/16W 0603
R4001-4003,R4011-4019 02-007-0357-00 RES SMD 75 OHM 5% 1/16W 0603
SMD CAPACITORS
C4001,C4009-4010 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
TAPE
C4006-4008 03-009-0136-00 CAP ELEC SMD 10uF 16V +/-20% 4X5.4
C4003-4005 03-009-0138-00 CAP ELEC SMD 1000uF 10V +/-20%
10x10.5
C4002 C4011-4019 03-009-0141-00 CAP ELEC SMD 2.2uF 50V +/-20% 4x5.4
HMDI BOARD
PCB ASSEMBLY 50-933-0775-90 T175/T775/T785 HDMI ASSY
INDUCTORS
L1 L2 07-002-0138-90 INDUCTOR AXIAL 180uH +/- 10%
2474R-28LK
L15 07-002-0148-90 INDUCTOR AXIAL 330uH 2.5A +/- 10%
SMD ICS
VR201 VR6 01-004-0057-90 IC VOLT REG. LM1117S-1.8 LOW
DROPOUT 1.8V 1A SOT-223
