NAD T 775 - Page 91

89
U20 01-010-0026-90 IC XC9572XL-5TQ100C IN-SYSTEM
PROGRAMMABLE CPLD SMD 100 PIN
TQFP
U2 U11 U16 U24 U32 01-012-0076-90 IC CM1213 8-Channel Low Capacitance
ESD Protection Arrays CM1213-08MR
U5 01-012-0077-90 IC PCA9517 LEVEL TRANSLATING I2C-
BUS REPEATER PCA9517D SMD SO8
U10 U201 01-012-0078-90 IC PCF8574 REMOTE 8-BIT I/O EX
PANDER FOR I2C-BUS PCF8574T SMD
SO16
U9 U13 01-012-0079-90 IC PI3B16233 3.3V 16-BIT TO 32-BIT
FET MUX/DEMUX NANOSWITCH
PI3B16233AE SMD TOSSOP 56PIN
(PERICOM)
U200 01-012-0082-90 IC LOGIC OCTAL BUFFERS/DRIVERS
WITH 3-STATE OUTPUTS 20PIN TSSOP
SN74AHCT244PWR (TI)
U18 U22 U26 01-014-0052-90 IC AD8061ART 300MHz RAIL-TO-RAIL
AMPLIFIER SMD 5-PINS SOT-23
U17 U21 U25 U27 U29 U30 01-014-0055-90 IC AD8063ARTZ 300MHz RAIL-TO-RAIL
AMPLIFIER SMD 6-PINS SOT-23
U19 01-026-0007-90 IC MC141585DW LCD MONITOR OSD
II - 16 SMD 16 PINS SOIC
U15 U23 01-028-0002-90 IC TMDS341PFC 3-TO-1 DVI/HDMI
SWITCH SMD 80 PINS PQFP
U28 01-029-0006-90 IC ADV7320KSTZ MULTIFORMAT
216MHz VIDEO ENCODER SMD 64 PINS
LQFP
U12 01-029-0007-90 IC ADV7403 INTEGRATED MULTIFOR
MAT SDTV/HDTV VIDEO DECODER
SMD 100 PINS LQFP
U14 01-029-0008-90 IC AD9388 10-BIT INTEGRATED MULTI
FORMAT VIDEO DECODER AD9388K
STZ SMD 144PIN LQFP
U31 01-029-0011-90 IC AD9389B 800MHz HIGH PERFOR
MANCE HDMI/DVI TRANSMITTER
AD9389KSTZ-80 SMD 80 PIN LQFP
VR3 01-030-0006-90 IC LM2575S-5.0 1A STEP-DOWN
VOLTAGE REGULATOR SMD 5 PIN
TO-263
VR4 01-030-0007-90 IC LM2575S-3.3 1A STEP-DOWN
VOLTAGE REGULATOR SMD 5 PIN
TO-263
VR2 U7 01-030-0008-90 IC VOLT REG. LOW DROPOUT 2.5V 1A
SOT-223 LM1117S-2.5
VR200 01-030-0009-90 IC LM1086CS-3.3 3.3V 1.5A LDO
VOLTAGE REGULATOR SMD 3 PIN
TO-263
SMD RESISTORS
RN1 RN2 RN3 RN4 RN5 RN6 RN7 02-003-0060-00 RES NETWORK 22 OHM X 8 5% 0.063W
RN8 RN9 RN10 RN1 RN12 RN13 TAPE 742C163220JP
R1 R2 R3 R4 R5 R11 R13 R14 R18 02-007-0028-00 RES SMD 4.7K OHM 5% 1/10W 0805
R28 R32 R64 R66 R200 R205
R82 02-007-0055-00 RES SMD 750 OHM 0805 5%
R20 02-007-0087-00 RES SMD 10K OHM 1/8W 0805 1%
R103-R106 02-007-0089-00 RES SMD 0 OHM 1/8W 0805 5%
R76 R87 R89 02-007-0311-00 RES SMD 1820 OHM 1% 1/10W 0805
R51 R61 R73 R77 R85 R90 R91 R94 R95 02-007-0320-00 RES SMD 301 OHM 1% 1/10W 0805
R43 R54 02-007-0326-00 RES SMD 4.64K OHM 1% 1/10W 0805
