90
R50 R53 R60 R72 02-007-0329-00 RES SMD 499 OHM 1% 1/10W 0805
R84 R92 R93 02-007-0332-00 RES SMD 604 OHM 1% 1/10W 0805
R29 R30 R35 R36 R37 R49 R41 R44 R59 02-007-0336-00 RES SMD 75 OHM 1% 1/10W 0805
R56 R57 R71 R63 R65 R75 R86 R88
R10 R12 R17 R19 R21 R33 R34 R45 R47 02-007-0340-00 RES SMD 1 OHM 5% 1/10W 0805
R52 R67 R68 R71 R74 R80 R81 R118
R210 R211 R212 R213
R6-R9 R24-R27 R38-R40 R42 R46 R55 02-007-0343-00 RES SMD 22 OHM 5% 1/10W 0805
R62 R69 R78 R79 R96 R102
R111-R116 R208 R209
R22 R23 R202 R203 02-007-0344-00 RES SMD 2.7K OHM 5% 1/10W 0805
R16 02-007-0353-00 RES SMD 47 OHM 5% 1/10W 0805
R98 02-007-0363-00 RES SMD 49.9K OHM 1% 0805 1/10W
R100 02-007-0364-00 RES SMD 680 OHM 1% 0805 1/10W
FB1 FB2 FB4 02-007-0366-00 EMI BEAD SMT 120 OHM 500mA 0603
R201 R83 02-007-0430-00 RES SMD 1.5K OHM 1% 1/10W 0805
R206 R207 02-007-0431-00 RES SMD 2.67K OHM 1% 1/10W 0805
R204 R15 02-007-0432-00 RES SMD 1.69K OHM 1% 1/10W 0805
R48 R70 R58 02-007-0484-00 RES SMDISTOR 1.3k OHM 0805 1%
R97 02-007-0486-00 RES SMD 887 OHM 0805 1%
R117 02-007-0487-00 RES SMD 18 OHM 1/10W 0805 1%
R31 02-007-0488-00 RES SMDISTOR 56 OHM 0805 1%
R99 R101 02-007-0492-00 RES SMD 3.01K OHM 0805 1%
SMD CAPACITORS
C18,C19,C22,C43,C47,C130,C160, 03-005-0015-00 CAP TANTALUM 10uF 10V +/- 10% A
C162,C204,C205,C206,C207,C236 CASE
C46,C50 03-005-0016-00 CAP TANTALUM 22uF 10V +/- 10% B
CASE
C9 C10 03-009-0073-00 CAP CER CAP 100pF/50V 5% NPO 0805
C1 C4 C13 C17 C21 C23-27 C29-34 03-009-0074-00 CAP CER CAP 0.1uF/50V 10% X7R 0805
C37-38 C41-42 C48 C52-53 C57-58
C60 C62 C64 C66-67 C69-74 C76
C79-86 C88-91 C95-115 C117-118
C120-123 C125-128 C141 C144
C146-148 C150-152 C155-156 C159
C161 C163-164 C166-171 C210-215
C227-234
C11 C12 C20 C51 C54 C59 C65 C77 03-009-0126-00 CAP CER SMD 10nF 50V 10% X7R 0805
C92-C94 C132-C136 C140 C142 C143
C145 C149 C153 C154 C157 C158
C201-C203 C216-C223 C238
C2 C3 C15 C16 C235 C237 03-009-0127-00 CAP CER SMD 1uF 16V +80/-20% Y5V
0805
C36 C40 C45 C224 C225 03-009-0132-00 CAP CER SMD 33pF 100V 0805 +/-5%
NPO
C14 C208 C209 03-009-0146-00 CAP CER SMD 0.082uF 25V 10% X7R
0805
C63 C68 C75 C78 03-009-0147-00 CAP CER SMD 10uF 10V +80% -20%
0805
C119 03-009-0148-00 CAP CER SMD 3900pF 50V 10% X7R
0805
C49 C55 C56 03-009-0149-00 CAP CER SMD 68pF 50V 5% NPO 0805
C116 03-009-0150-00 CAP CER SMD 820pF 50V 10% X7R
0805
C35 C39 C44 03-009-0151-00 CAP CER SMD 82pF 50V 5% NPO 0805
C5 C7 03-009-0152-00 SMD E CAP 100uF/16V ±20% LOW
IMPEDANCE D CASE 6.3 X 5.8
