NAD T 775 - Page 93

91
C6 C8 03-009-0154-00 SMD E CAP 220uF/16V ±20% LOW
IMPEDANCE D CASE 6.3 X 7.7
C28 03-009-0165-00 CAP CER SMD 1000pF 100V +/-5% NPO
0805
C200 03-009-0186-00 CAP CER SMD 8200pF 50V 10% C0G
0805
SMD DIODES
D1 D2 04-001-0049-90 DIODE SHKY 1A/40V DO-213AB SM5819
SMD TRANSISTORS
Q1-Q5 05-004-0035-90 TRANSISTOR SS NPN HFE30 250MHz
SPT DTC114EKAT146
SMD INDUCTOR
L3 L5 L7 07-007-0020-90 IND SMD 220nH 10% 0805
L9 L10 L11 L12 L13 L14 07-007-0021-90 IND SMD 3.3uH 10% 0805
L4 L6 L8 07-007-0022-90 IND SMD 470nH 10% 0805
SMD OSCILLATOR
X200 14-004-0018-90 CRYSTAL 28.63636MHz 30ppm 18pF
SMD HC-49SM
01-CR1-03-28M63636-18-3030
U3 14-004-0022-90 CRYSTAL OSCILLATOR 28.63636MHz
+/-50ppm 3.3V SMD
SMD FUSE
F200 20-006-0007-90 SMD Fuse SMD2920P075TF 0.75A
Circuit Breaker Resettable VDE
MCU BOARD
PCB ASSEMBLY*AH 50-937-0775-90 T775 AH MCU ASSY
PCB ASSEMBLY*C,CT 50-946-0775-90 T775 C/CT MCU ASSY
SMD ICS
U2008 01-004-0056-90 IC VOLT REG. LOW DROPOUT 3.3V 1A
SOT-223 LM1117S-3.3
U2006 01-008-0007-90 IC MICROPOWER UP WATCH DOG
TIMER 2.93V SOT-25
AME8530AEEVEFX29Z
U2001 01-010-0025-90 IC M30280FCHP-U3 16-BIT MCU 128K
ROM 12K RAM QFP 80P6Q-A
U2007 01-010-0030-90 IC MCU 8 BITS 8K ROM 512 BYTES
RAM TQFP ATMega48-20
U2002 01-011-0034-90 IC LE030401 AT24C16-AN-2.7 ATMEL
U2009 01-012-0059-00 IC LOGIC QUAD 2-INPUT NAND GATE
SOP 74HC00D
U2005 01-012-0073-90 IC 74HC132D LOGIC QUAD 2-INPUT
NAND SCHMITT TRIGGER SMD 14 PINS
SOIC
SMD RESISTORS
R2026 02-007-0042-00 RES SMD 1K OHM 0603 5%
L2001 02-007-0089-00 RES SMD 0 OHM 1/8W 0805 5%
R2011 02-007-0094-00 RES SMD 1K OHM 1/4W 1206 1%
R2013-2014 R2022 R2028 R2044 02-007-0139-00 RES SMD 4.7K OHM 0603 5%
R2004 R2009 R2002 R2019-2021 02-007-0157-00 RES SMD 10K OHM 0603 1%
R2023 R2025 R2027 R2043
