NAD T 775 - Page 94

92
R2001 R2007 02-007-0267-00 RES SMD 100K OHM 5% 1/16W 0603
R2003 R2010 R2012 R2015-2016*AH 02-007-0288-00 RES SMD 0 OHM 5% 1/16W 0603
R2017-2018*C CT R2024 R2041 R2042
R2031-R2038 02-007-0292-00 RES SMD 2.2K OHM 1% 1/16W 0603
SMD CAPACITORS
C2002-2003 C2006-2007 C2010 C2019 03-009-0075-00 CAP CER SMD 0.1uF 50V 20% Y5V 0603
C2022 C2023 C2026 C2028 C2030 TAPE
C2032 C2033
C2017 03-009-0112-00 CAP CER SMD 1nF 50V 10% X7R 0603
C2009 03-009-0136-00 CAP ELEC SMD 10uF 16V +/-20% 4X5.4
C2008 03-009-0138-00 CAP ELEC SMD 1000uF 10V +/-20%
10X10.5
C2018 03-009-0139-00 CAP ELEC SMD 0.1uF 50V +/-20% 4X5.4
C2001 03-009-0140-00 CAP ELEC SMD 22uF 16V +/-20% 5X5.4
C2004-2005, C2021 C2024 C2025 03-009-0143-00 CAP ELEC SMD 47uF 50V +/-20%
C2027 C2029 C2031 6.3X7.7
C2020 03-009-0153-00 SMD E CAP 1uF/50V ±20% B CASE 4 X
5.4
SMD DIODES
D2001 04-006-0021-90 SMD Diode LL4148 SOD80
SMD TRANSISTORS
Q2007 05-004-0020-00 SMD Transistor T3904 SOT-23
Q2008 Q2009 Q2010 Q2011 Q2012 05-004-0035-90 TRANSISTOR SS NPN HFE30 250MHz
SPT DTC114EKAT146
Q2001-Q2004 05-004-0037-90 TRANSISTOR SS PNP HFE 30 250MHz
SPT DTA114EKAT146
SMD OSCILLATOR
X2001A 14-004-0019-90 CRYSTAL OSCILLATOR 20.000MHz 5V
50ppm 15pF SMD
CONNECTOR #1 BOARD
PCB ASSEMBLY 50-938-0775-90 T765/T775/T785 CONNECTION # 1
ASSY
CONNECTOR #2 BOARD
PCB ASSEMBLY 50-942-0775-90 T775/T785 CONNECTION # 2 ASSY
CONNECTOR #3 BOARD
PCB ASSEMBLY 50-943-0765-90 T765/T775/T785 CONNECTION # 3
ASSY
CONNECTOR #4 BOARD
PCB ASSEMBLY 50-944-0775-90 T775/T785 CONNECTION # 4 ASSY
