NAIM NAC 552 - NAC 202 Connected to Hi-Cap and NAPSC; NAC 152 XS Connected to FlatCap (both outputs)

E14
NAC 282, NAC 202 & NAC 152 XS
12.3 NAC 202 Connected to Hi-Cap and NAPSC
12.4 NAC 152 XS Connected to FlatCap (both outputs)
mains input
and fuse
to stereo power amplier
to mono or dual
mono power
ampliers
additional
signal output
mains input
and fuse
power
switch
to stereo
power amplier
to mono or dual
mono power
ampliers
additional signal
output
cable
direction
marker
Interconnect Cables
240° 5 to 5 pin DIN
