NAIM SUPERNAIT 2 - Controls and Connections; Front Panel Controls; Rear Panel Connections

E12
NAIT XS 2
10 Controls and Connections
10.1 Front Panel Controls
volume
mute
source selection
headphone socket
signal
ground
aux 2
in &
power
out
remote in
mains
input
and fuse
left
speaker
right
speaker
power
preamp out
and power
amp in. Link
plug tted.
av in
& out
hdd
in &
out
tuner
in
cd in
AV
bypass
switch
subwoofer
out
aux 1 in
RCA
av in
RCA
hdd in
RCA
tuner in
RCA
cd in
RCA
10.2 Rear Panel Connections
ch1
-ve
nc
nc
ch2
cd and tuner
Inputs
ch1
-ve
ch1
(out)
ch2
(out)
ch2
av and hdd
Inputs
+ve
-ve
+ve
ch1
ch2
aux 2 input
Note: The link plug should be removed only if a power
supply upgrade is to be used, an alternative preamplifier
is to use the Nait XS 2 power amplifier section, or an
alternative power amplifier is to use the Nait XS 2
preamplifier section. It should remain fitted in all other
circumstances.
Note: The Nait XS 2 features various technologies to reduce
microphonic effects. Some movement of the board and
sockets when connecting and disconnecting cables is
normal.
ch2 ch2
ch1 ch1
nc +ve
-ve -ve
preamp out power amp in
USB
update
interface
