NAiS FP0 Series User Manual

Analog I/O Unit
FP0
4-5
Matsushita Automation Controls
4.2 Specifications
4.2 Specifications
4.2.1 General Specifications
Item Description
Rated operation voltage
24 V DC
Operating voltage range
21.6 to 26.4 V DC
Rated current consumption
100 mA or less (
*
section 2.2.1.2)
Allowed momentary power
off time
10 ms
Ambient temperature
0
q
C to +55
q
C/32
q
F to +131
q
F
Storage temperature
-20
q
C to +70
q
C/- 4
q
F to +158
q
F
Ambient humidity
30% to 85% RH (non-condensing)
Storage humidity
30% to 85% RH (non-condensing)
Breakdown voltage
500 V AC for 1 minute between I/O terminal and power
supply/ground terminal
500 V AC for 1 minute between input and output terminals
Insulation resistance
min. 100 M
Ω
(measured with a 500 V DC megger) for
between I/O terminal and power supply/ground terminal
min. 100 M
Ω
(measured with a 500 V DC megger) for
between input and output terminals
Vibration resistance
10 Hz to 55 Hz, 1 cycle/min: double amplitude of 0.75 mm/
0.030 in., 10 min on 3 axes
Shock resistance
Shock of 98 m/s
2
or more, 4 times on axes
Noise immunity
1,000 Vp-p with pulse widths 50 ns and 1
μ
s (based on
in-house measurements)
Operating condition
Free from corrosive gases and excessive dust
4.2.1.1 Weight
Type Weight
A21
approx. 100 g/3.53 oz
